1250kVA Cummins C1250D5P Silent Diesel Generator

TECHNICAL DATA SHEET OF TRANSFORMERS
Service Location	All Over India
Dimensions (L x W x H)	2978 x 2080 x 1780 mm
Bore (mm) x Stroke (mm)	159 mm x 159 mm
Brand	Cummins
Power Rating	1250kVA
Genset Model	C1250D5P
Engine Model	KTA50-G3
BHP	1470
Alternator Frame	HCK6Z
Genset Controller	PC3.3
Output Voltage	415 Volts
Frequency	50 Hz
Power Factor	0.8 (lag)
Phase	Three Phase
No. of Cylinders	16 'Vee'
Displacement	50.3 ltrs
Output - Prime	1470 bhp (1097 kWm) 1
Compression Ratio	13.9:1
Piston Speed	7.95 m/s
Lubricating Oil Sytem Capacity	177 Litre
Coolant capacity (engine + radiator)	440 Litre
Fan Air Flow Across Radiator	27357 ltrs/sec
Exhaust Temperature	529 Degree Celsius
Insulation	Class H
Standard Enclosure	IP 23
Lubricating Oil Sytem Capacity	177 Litre
Stator Winding	Double Layer Lap
Telephone interference Factor	50%
Total Harmonic Factor	2%
Genset Dimensions	5212x2179x3001 mm
Weight	11235 kg
Fuel Tank Capacity	990 Litre

Phone: +91-8700249494

Cummins® ‘K50 series’ diesel engine with strong regrindable crankshaft, high strength connecting rod, low pressure fuel lines, STC (Step Timing Controls) injectors and high volume coolant system make ‘K50 series’ generating sets, more reliable and durable. Engines have clocked millions of hours operating in some of the world’s most demanding conditions. Current engines are regularly upgraded with new technologies for better performance and economy. The ultimate proof of superior performance and reliability is the fact that Cummins® entities worldwide source these engines from Cummins India for their markets.

Unmatched Warranty:

ZCummins® ‘K50 series’ diesel engine generating sets are a truly cost effective solution to long term power need backed by industry best, 2 years / 5000 hrs warranty, for the entire generating set. With superior experience in technology, design capability and commitment reliability and quality we offer an unmatched 5 years or 5000 hours (including above 2 years) warranty coverage on 5 critical components (5C) of the engine – Cylinder Head, Camshaft, Crankshaft, Cylinder Block, Connecting Rod against manufacturing defect.

Cummins Advantage:

Special features of Cummins® ‘K50 series’ engines like STC (Step Timing Controls) injectors, low temperature aftercooler, square cumbustion chamber, optimised turbocharging and precision heavy duty camshaft make these engines the ultimate in exceptional fuel efficiency all across the operating range.

Single Source Power Assurance:

Design, manufacture and testing of engine, alternator and other accessories is done by Cummins Group of companies for optimum performance and is backed by a countrywide product support network with a single source responsibility for the entire package.

Standard Scope:

Engine Cummins® ‘K50 series’ direct injection, water cooled engine, 16 cylinder, 4 stroke, rated at 1500 RPM, conforming to ISO 3046 / IS 13018 has the following. specifications:
Cummins PT fuel pump
Cummins heavy duty ESTC injectors
Holset turbocharger, pulse tuned exhaust manifold,
stainless steel exhaust flexible connections
Radiator or heat exchanger, coolant inhibitor
Plate type lube oil cooler
Outboard aftercoolers
Full flow paper element filters - fuel, lube oil and bypass
Dry type replaceable paper element air cleaner with
restriction indicator
Flywheel housing & flywheel to suit single/ double
bearing alternator
Holset flexible coupling for double bearing alternator
Starting motor – Electric, battery charging alternator
Cummins PowerCommand® microprocessor based
genset controller
First fill lube oil and coolant.

Alternator:

Accessories:
